Pelletizer machine Ball Granulating Machine for capsule and pills
Industrial Fertilizer Granulator Machine / Ball Granulating Machine For Capsule
Application
With the special design of rotor structure, the machine makes various wet grains into the perfect ball shape pellets. It is the desired equipment for making the capsules and pills of traditional Chinese medicine.
1. Pharmaceutical, Food Industries
2. Cosmetic, Dyestuff, Coloring Industries 3. Ceramic Industry
Woking princple
Pelletizer machine Ball Granulating Machine for capsule and pills Equipmentmakes damp granule into beautiful pellet by setting rotating centrifugal disk, blower, and pneumatic nozzle. Feed damp granule into rotating centrifugal disk, start fan then start rotating centrifugal disk. It can make the damp granule in float and circle by the air from gap, rotating centrifugal strength and itself gravity, appear circle rope-turning movement and become high-degree ball shape pellet.
Pelletizer machine Ball Granulating Machine for capsule and pills makes damp granule into beautiful pellet by setting rotating centrifugal disk, blower, and pneumatic nozzle. Feed damp granule into rotating centrifugal disk, start fan then start rotating centrifugal disk. It can make the damp granule in float and circle by the air from gap, rotating centrifugal strength and itself gravity, appear circle rope-turning movement and become high-degree ball shape pellet.
Technical Parameters
| | | | | | | |
| Specification | 230 | 400 | 500 | 700 | 1000 | 1300 |
| Power ( Kw ) | 0.75 | 2.2 | 3 | 3.7 | 5.5 | 7.5 |
| Capacity ( kg/h ) | 2.5-4 | 5-8 | 8-16 | 40-80 | 70-150 | 100-300 |
All dates for reference only. According to the material features, we have the right to change but not notice, pardon!
Product Tags:
|
|
Ball Granulating 3.7Kw Fertilizer Granulator Machine Images
|
